OPC server
YYO 300
How energy efficiency is improved
SAUTER EY-modulo 2 – thoroughly proven technology in a new design – can be integrated into any visualisation and energy management system using the standard OPC interface.
Jellemzők
-
Integration of novaNet stations from the EY-modulo 2 and EY3600 ranges
-
novaNet bus access with the devices
-
a. novaNet291 router as a direct connection or via modem for a remote connection
-
b. moduNet292-novaNet-Ethernet interface
-
-
Data exchange for status, commands, measured values and setpoints
-
Query of historical data
-
Display and setting of time programmes and calendars in the stations (ActiveX components)
-
OPC specification: In accordance with OPC Data Access 2.0 (OPC DA 2.0)
-
For visualisation software with OPC client function and optional support for ActiveX
-
Windows operating systems:
-
Windows XP Professional, Windows 7 (32- and 64-bit), Windows Server 2008
-
-
PC interfaces:
-
EIA-232 (COM port for novaNet291/router)
-
EIA-232/modem (modem interface for dial-up operation with novaNet291/router)
-
Ethernet (via novaVPort driver for moduNet292)
-
